IP Route Parameters

Router
Metric Count
Route Type
Route Destination
Destination Mask
Configuring IP
Parameter
Router
Metric Count
Route Type
Route Destination
Destination Mask
is the IP address of a router that can reach the route destination.
is the number of "hops" (network gateways in the overall path over the internet) from
the source to the destination.
= Network – defines a route for a network.
0
1 = Host – defines a route for a specific host.
= Default – defines a route that will be used if no other route is found.
2
is the IP address of the destination for host routes.
is the mask used for network routes. It is used only during routing, to determine the
portion of the address associated with the destination.
When an IP datagram is received, the software searches for a match to the destination
address in the node's IP routing table. If there is no match, then destination masks are
checked. If no match is found here either, the default route (if configured) will be used.
(If the default route is not configured, the datagram will be discarded, and an error
message will be sent to the source.)
Table 14-2 IP Route Parameters
Valid Values
valid IP address
0–255
0–2
valid IP address or 0
valid IP address
Default Value
255.255.255.255
1
0 (Network)
0.0.0.0
255.255.255.255
14-9
