Filter Parameters
RIP Filter Parameters
Filter Name
Network Address Value
Configuring IPX
The mask will also be ANDed to its corresponding field in each IPX packet as deter-
mined by IPX Filter Applications (described on
pared to the AND result of the configured value and mask. If the two results match,
the filter will be applied. This process allows a number of packet field values to match
the AND result of the mask and value; for example:
Packet field =
1233
Binary value:
001001000110011
Mask:
101011001111000
AND Result:
001001000110000
The following four tables list the IPX filter parameters. Explanations follow the tables.
Explanations of individual masks are not included below because they
were described in general on
Parameter
Filter Name
Network Address Value
Network Address Mask
helps the user identify the filter. The name is not used by the software.
is a number assigned to the local network.
, Mask = :Packet field =
5678
Value:
Mask:
AND Result:
page 15-12.
Table 15-5 IPX RIP Filter Parameters
Valid Values
1–31 characters
0–ffffffff
0–ffffffff
page 15-16). This result will be com-
, Mask =
1237 5678
001001000110111
101011001111000
001001000110000
Default Value
none
(4 bytes) ffffffff
(4 bytes) ffffffff
:
15-13
