10 –

Removing and installing engine

1 Removing and installing engine
⇒ "1.1 Removing engine", page 11
⇒ "1.2 Securing the engine to the assembly stand", page 21
⇒ "1.3 Installing engine", page 22
1.1

Removing engine

Special tools and workshop equipment required
♦ Removal tool for inner lining of the door panel - MP8-602/1-
♦ Extension - 2024 A /1- of lifting device - MP9-201 (2024A)-
♦ Engine and gearbox jack - V.A.G 1383 A-
♦ Engine bracket - T10497-
♦ Catch pan for workshop crane , e.g. -VAS 6208-
♦ Hose clip pliers, e.g. - VAS 6362-
♦ Locking pin - T10060 A-
♦ Double ladder , e. g. -VAS 5085-
♦ Grease - G 000 100-
♦ Protective goggles
♦ Protective gloves
Work procedure
Note
The engine is removed downwards together with the gearbox.
♦
All cable straps that have been loosened or cut open when the
♦
engine was removed must be attached again in the same lo‐
cation when the engine is installed again.
Leave the ignition key in the ignition lock so that the steering
♦
lock does not click into place.
Collect drained coolant in a clean container for reuse or proper
♦
disposal.
WARNING
There is risk of injury from high fuel pressure.
♦ Before opening the high-pressure system, the fuel pres‐
sure must be reduced to residual pressure.
– Reduce the fuel pressure in the high pressure system
⇒ "3.10 Reduce pressure in the high-pressure system",
page 10 .
Octavia III 2013 ➤ , Octavia III 2014 ➤
1.2/63; 77 kW TSI engine - Edition 11.2014
1. Removing and installing engine
11
