Octavia III 2013 ➤ , Octavia III 2014 ➤
1.2/63; 77 kW TSI engine - Edition 11.2014
– Carefully lever off sump from cylinder block at recess -arrow-
using assembly lever.
– Remove sump. Loosen sump with light blows of a rubber
headed hammer if necessary.
WARNING
Wear protective gloves when working with sealant and grease
remover!
– Remove the remaining sealant on the cylinder block and on
the oil pan with chemical sealant remover.
– Degrease the sealing surfaces.
Install
Note
Pay attention to the use by date on sealant.
♦
The oil pan must be installed within 5 minutes after applying
♦
the sealant.
The sump can be positioned more easily and with greater se‐
♦
curity if M6 studs are inserted into the cylinder block flange at
two positions as guides.
