Skoda Octavia III 2013 Workshop Manual page 161

1 - Thermostat housing
❑ installing and removing
⇒ "2.7.2 Removing and
installing thermostat for
large coolant circuit",
page 167
❑ Observe tightening se‐
quence when tightening
to coolant pump
⇒ "2.4 Removing and in‐
stalling coolant pump",
page 158 .
2 - Thermostat
❑ For large coolant circuit
❑ Start of opening approx.
105 ℃
❑ different versions ⇒
Electronic Catalogue of
Original Parts"ETKA"
❑ installing and removing
⇒ "2.7.2 Removing and
installing thermostat for
large coolant circuit",
page 167
3 - Gasket
❑ replace after removal
❑ Observe proper seating
of gasket
❑ before installing, slightly
moisten with coolant
4 - Coolant pump
❑ installing and removing
⇒ "2.4 Removing and in‐
stalling coolant pump",
page 158
❑ Replace toothed belt when changing coolant pump
5 - Bolt
❑ order of tightening
❑ 8 Nm
6 - Gasket
❑ replace after removal
❑ Observe proper seating of gasket
❑ before installing, slightly moisten with coolant
7 - Toothed belt guard
❑ For coolant pump toothed belt
8 - Bolt
❑ replace after removal
❑ 20 Nm + torque a further 90° (
9 - Toothed belt
❑ Replace when changing coolant pump
❑ For coolant pump drive
❑ installing and removing
10 - Toothed belt pulley
❑ For coolant pump drive
⇒ page 156
1
/ 4 turn)
⇒ "2.4 Removing and installing coolant pump", page 158
Octavia III 2013 ➤ , Octavia III 2014 ➤
1.2/63; 77 kW TSI engine - Edition 11.2014
2. Coolant pump, regulation of cooling system
155
