Skoda Octavia III 2013 Workshop Manual page 242

Octavia III 2013 ➤ , Octavia III 2014 ➤
1.2/63; 77 kW TSI engine - Edition 11.2014
1.1.2 Installation overview - engine from front
1 - Knock sensor 1 - G61-
❑ Summary of compo‐
nents
⇒ "1.1 Assembly over‐
view - ignition system",
page 281
2 - Oil pressure switch for re‐
duced oil pressure - F378-
❑ Summary of compo‐
nents
⇒ "4.2 Removing and
installing oil pressure
switch for reduced oil
pressure F378 ",
page 141
3 - Fuel pressure sender -
G247-
❑ Summary of compo‐
nents
⇒ "4.1 Assembly over‐
view - fuel rail with injec‐
tors", page 248
4 - Activated charcoal filter sol‐
enoid valve 1 - N80-
5 - Injectors
♦ Injector, cylinder 1 - N30-
♦ Injector, cylinder 2 - N31-
♦ Injector, cylinder 3 - N32-
♦ Injector, cylinder 4 - N33-
❑ Summary of compo‐
nents
⇒ "4.1 Assembly over‐
view - fuel rail with injec‐
tors", page 248
6 - Control valve for fuel pressure - N276-
❑ on the high pressure pump
❑ Summary of components
7 - Engine speed transmitter - G28-
❑ Summary of components
236
Rep. gr.24 - Mixture preparation - injection
⇒ "6.1 Summary of components - high pressure pump", page 261
⇒ "1.1 Assembly overview - ignition system", page 281
