Verify the PCIe Card

/SYS/CMIOU9/PCIE2/IOVFC.PF0.VF2
/SYS/CMIOU9/PCIE2/IOVFC.PF0.VF3
In this example, the virtual functions listed under the TYPE column now displays a domain
name.
Related Information
Oracle VM Server for SPARC documentation (http://www.oracle.com/goto/vm-sparc/docs)
■
"Prepare a PCIe Card For Removal" on page 151
■
Verify the PCIe Card
Note -
card documentation for the firmware update instructions.
1. Verify that the Fault LED is not lit and that the green Power LED is lit on the card
that you installed.
See "PCIe Card Carrier LEDs and Controls" on page
2.
At a terminal, use the hotplug command to ensure that the card is connected.
For example:
# hotplug list /SYS/CMIOU0/PCIE1
Related Information
"Identify Faulted Components" on page 36
■
"Interpreting LEDs" on page 44
■
164 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
Always update PCIe card firmware to the latest supported version. Refer to the PCIe
[/SYS/CMIOU0/PCIE1] ENABLED
network@0 <pci.0,0> ONLINE
network@0,1 <pci.0,1> ONLINE
network@0,2 <pci.0,2> ONLINE
network@0,3 <pci.0,3> ONLINE
VF pci_45 ldg4
VF pci_45 ldg4
149.
