Servicing Internal Interconnect Assemblies - Oracle SPARC M8 Service Manual

Servicing Internal Interconnect Assemblies

In SPARC M8-8 and SPARC M7-8 servers, five internal interconnect assemblies in the CMIOU
chassis connect the CMIOUs to each other.
For the location of the internal interconnect assemblies, see
Components" on page 20.
This procedure requires that you handle components that are sensitive to electrostatic
Caution -
discharge. This discharge can cause server components to fail. Follow antistatic precautions to
prevent electrostatic damage. See
These topics explain how to service internal interconnect assemblies.
Step Description
1. Understand interconnect slot labels and configuration.
2. Replace an internal interconnect assembly.
Related Information
"Identifying Components" on page 15
■
"Detecting and Managing Faults" on page 35
■
"Preparing for Service" on page 57
■
"Controlling the Server and Domains" on page 67
■
"Understanding Server Configurations and Failover Behavior" on page 79
■
"Prevent ESD Damage" on page
Links
"Internal Interconnect Assembly
Configuration" on page 298
"Remove an Internal Interconnect
Assembly" on page 299
"Install an Internal Interconnect
Assembly" on page 302
Servicing Internal Interconnect Assemblies
"CMIOU Chassis Front
61.
297
