Component
FPGA (SPP) SSI links (SPARC M7-16)
FPGA (switch unit)
Front indicator panel (SPARC M8-8 and
SPARC M7-8)
Front indicator panel (SPARC M7-16)
ICID (SPARC M8-8 and SPARC M7-8)
ICID (SPARC M7-16)
Interconnects
PCIe cards
PCIe card carriers
PDECBs
Power supplies
Rear indicator panel (SPARC M8-8 and
SPARC M7-8)
Rear indicator panel (SPARC M7-16)
Oracle ILOM Target Name Reported
/SYS/SPPx/FPGA/SSI_LINKy
x is 0–3, y is 0–7
/SYS/SWUx/FPGA
x is 0–5
/SYS/FOPNL
/SYS/FOPNLx
x is 0–2
/SYS/ICID
/SYS/ICIDx
x is 0–2
/SYS/ITx/interconnect-name
See "CMIOU Chassis Rear Components" on page
interconnect names.
See "Switch Chassis Rear Components (SPARC M7-16)" on page 25
interconnect names.
/SYS/CMIOUx/PCIEy
/SYS/CMIOUx/PCIEy/CAR
SPARC M8-8: x is 0–7, y is 1–3
SPARC M7-8: x is 0–7, y is 1–3
SPARC M7-16: x is 0–15, y is 1–3
/SYS/PDECBx
SPARC M8-8: x is 0–7
SPARC M7-8: x is 0–7
SPARC M7-16: x is 0–21
/SYS/PSx
SPARC M8-8: x is 0–5
SPARC M7-8: x is 0–5
SPARC M7-16: x is 0–15
/SYS/ROPNL
/SYS/ROPNLx
x is 0-2
Identify Disabled Components
21for SPARC M8-8 and SPARC M7-8
for SPARC M7-16
