Card Installation Bottom Cmiou Chassis (Servers With Multiple Pdomains) - Oracle SPARC M8 Service Manual

PCIe Card Installation Order Guidelines
"Card Installation Bottom CMIOU Chassis (Servers With Multiple
■
PDomains)" on page 146
"Card Installation Bottom CMIOU Chassis (SPARC M7 With One
■
PDomain)" on page 147
"Card Installation Top CMIOU Chassis (SPARC M7-16)" on page 148
■
Card Installation Bottom CMIOU Chassis (Servers
With Multiple PDomains)
For SPARC M8-8 and SPARC M7-8 servers with two PDomains and SPARC M7-16 servers,
install PCIe cards in fully populated configurations in the order shown.
No.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
146 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
PDomain
PDomain_0
PDomain_0
PDomain_0
PDomain_1
PDomain_1
PDomain_1
PDomain_0
PDomain_0
PDomain_0
PDomain_1
PDomain_1
PDomain_1
PDomain_0
PDomain_1
PDomain_0
PDomain_1
PDomain_0
PDomain_0
PDomain_0
PDomain_0
PDomain_1
PDomain_1
CMIOU
CMIOU_0
CMIOU_1
CMIOU_2
CMIOU_4
CMIOU_5
CMIOU_6
CMIOU_0
CMIOU_1
CMIOU_2
CMIOU_4
CMIOU_5
CMIOU_6
CMIOU_3
CMIOU_7
CMIOU_3
CMIOU_7
CMIOU_0
CMIOU_1
CMIOU_2
CMIOU_3
CMIOU_4
CMIOU_5
PCIe Slot Card to Install
Storage card
PCI3
Network card
PCI3
PCI3
Storage card
PCI3
Network card
PCI3
PCI3
PCI1
PCI1
PCI1
PCI1
PCI1
PCI1
PCI3
PCI3
PCI1
PCI1
PCI2
PCI2
PCI2
PCI2
PCI2
PCI2
