Remove a Switch Chassis
See
"Removing Power From the Server or Domain" on page
At the front of the server, remove the power supplies.
3.
See
"Servicing Power Supplies" on page
4.
At the rear of the server, remove all of these components in the order indicated.
Component
Cables
SPs
SP tray
Switch units
PDECBs
Power module, including AC inlet strip and front
indicator panel
Caution -
mechanical lift.
5.
At the front of the server, remove all of these components:
Component
External interconnects
SP interconnect
278
SPARC M8 and SPARC M7 Servers Service Manual • September 2017
Do not attempt to remove the chassis alone without the aide of another person or a
69.
165.
Link
Ensure that you label the cables.
"Servicing SPs" on page 117
"Servicing SP Trays" on page 243
"Servicing Switch Units" on page 189
"Servicing PDECBs" on page 199
"Servicing Power Modules" on page 235
Link
"Servicing External Interconnect Assemblies" on page 305
"Servicing SP Internal Interconnect Assemblies" on page 285
