No. PDomain
23.
PDomain_1
24.
PDomain_1
Card Installation Bottom CMIOU Chassis (SPARC
M7 With One PDomain)
For SPARC M8-8 and SPARC M7-8 servers that has one PDomain, install PCIe cards in fully
populated configurations in the order shown.
No. CMIOU
1.
CMIOU_0
2.
CMIOU_1
3.
CMIOU_2
4.
CMIOU_4
5.
CMIOU_5
6.
CMIOU_6
7.
CMIOU_0
8.
CMIOU_1
9.
CMIOU_2
10.
CMIOU_4
11.
CMIOU_5
12.
CMIOU_6
13.
CMIOU_3
14.
CMIOU_7
15.
CMIOU_3
16.
CMIOU_7
17.
CMIOU_0
18.
CMIOU_1
19.
CMIOU_2
20.
CMIOU_3
21.
CMIOU_4
22.
CMIOU_5
23.
CMIOU_6
24.
CMIOU_7
CMIOU
CMIOU_6
CMIOU_7
PCIe Slot
PCI3
PCI3
PCI3
PCI3
PCI3
PCI3
PCI1
PCI1
PCI1
PCI1
PCI1
PCI1
PCI3
PCI3
PCI1
PCI1
PCI2
PCI2
PCI2
PCI2
PCI2
PCI2
PCI2
PCI2
PCIe Card Installation Order Guidelines
PCIe Slot Card to Install
PCI2
PCI2
Card to Install
Storage card
Storage card
Network card
Network card
Servicing PCIe Cards 147
