CMIOU Chassis Rear Components

Access these components from the rear of the server. These components are not part of the
chassis. You must remove these components to access the chassis.
Description
■ Right side, top to bottom: FM_7, FM_5, FM_3,
FM_1
Top CMIOU chassis:
■ Left side, top to bottom: FM_14, FM_12, FM_10,
FM_8
■ Right side, top to bottom: FM_15, FM_13, FM_11,
FM_9
Internal interconnects (5), left to right (SPARC
M8-8 or SPARC M7-8 with two PDomains):
■ II_N_24_L (slot IT_0)
■ II_N_24_L (slot IT_1)
■ II_W_248 (slot IT_2)
■ II_N_24_R (slot IT_3)
■ II_N_24_R (slot IT_4)
Internal interconnects (5), left to right (SPARC
M8-8 or SPARC M7-8 with one PDomain):
■ II_N_8_LO (slot IT_0)
■ II_N_8_LI (slot IT_1)
■ II_W_248 (slot IT_2)
■ II_N_8_RI (slot IT_3)
■ II_N_8_RO (slot IT_4)
SP internal interconnects (1 per CMIOU chassis):
II_CMIOU_SP (slot CMIOU SP IT_5)
Power supplies (6 per CMIOU chassis)
■ Bottom CMIOU chassis, top to bottom:
PS5–PS0
■ Top CMIOU chassis, top to bottom: PS15–PS10
CMIOU Chassis Rear Components
Links
"Servicing Internal Interconnect
Assemblies" on page 297
"Servicing SP Internal Interconnect
Assemblies" on page 285
"Servicing Power Supplies" on page 165
