Mixed CMIOU Configurations

The following configurations are supported on a SPARC M7-16 server.
CMIOU_0 and CMIOU_1 in PDomain_0,
■
CMIOU_4 and CMIOU_5 in PDomain_1,
CMIOU_8 and CMIOU_9 in PDomain_2, and
CMIOU_12 and CMIOU_13 in PDomain_3
CMIOU_0 – CMIOU_3 in PDomain_0,
■
CMIOU_4 – CMIOU_6 in PDomain_1,
CMIOU_8 – CMIOU_10 in PDomain_2, and
CMIOU_12 – CMIOU_14 in PDomain_3
CMIOU_0– CMIOU_3 in PDomain_0,
■
CMIOU_4 – CMIOU_7 in PDomain_1,
CMIOU_8 – CMIOU_11 in PDomain_2, and
CMIOU_12 – CMIOU_15 in PDomain_3
Note -
Configurations" on page 86
For information about the PCIe slots that are available in each of these configurations, see
"Understanding PCIe Card Device and Service Paths" on page
Caution -
Related Information
"SPARC M7-16 Configurations and Failover Behavior" on page 81
■
Mixed CMIOU Configurations
The SPARC M7-8 server configured with two static PDomains is the only server that supports
a mixed configuration of SPARC M7 and SPARC M8 CMIOUs. In a SPARC M7-8 server with
two static PDomains, SPARC M8 CMIOUs can be installed in PDomain_1 (slots CMIOU_4 to
CMIOU_7). SPARC M8 CMIOUs are not supported in PDomain_0 (slots CMIOU_0 to CMIOU_3) of a
SPARC M7-8 server with two PDomains.
86 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
The SPARC M7-16 server does not support SPARC M8 CMIOUs. See
for more information.
To prevent overheating, fill unused CMIOU slots with CMIOU filler panels.
"Mixed CMIOU
143.
