If the PCIe card is not assigned to an I/O domain, see
■
Card From the Server" on page
Related Information
"PCIe Card Slot Configuration and Numbering" on page 142
■
"Understanding PCIe Card Device and Service Paths" on page 143
■

Prepare a PCIe Card For Removal

If the PCIe card is assigned to an I/O domain on a logical domain, use these steps to avoid a
configuration that is unsupported by the SR-IOV feature.
If the PCIe card is not assigned to an I/O domain on a logical domain, go to
Card Carrier and Card From the Server" on page
1. Determine which PCIe card requires service.
In this example, pci_45 represents the I/O domain name.
The following example shows only an excerpt of the output.
Note -
# ldm ls-io -l pci_45
NAME
----
pci_45
[pci@32d]
/SYS/CMIOU9/PCIE2
[pci@32d/pci@1]
SUNW,qlc@0/fp/disk
SUNW,qlc@0/fp@0,0
SUNW,qlc@0,1/fp/disk
SUNW,qlc@0,1/fp@0,0/ssd@w20350080e518b846,1f
fibre-channel@0,2
fibre-channel@0,3
fibre-channel@0,4
fibre-channel@0,5
...
/SYS/CMIOU9/PCIE2/IOVFC.PF0.VF0
[pci@32d/pci@1/SUNW,qlc@0,2]
Class properties [FIBRECHANNEL]
port-wwn = 10:00:00:14:4f:f8:74:85
node-wwn = 20:00:00:14:4f:f8:74:85
"Remove a PCIe Card Carrier and
156.
156.
TYPE BUS
---- ---
BUS pci_45
PCIE pci_45
VF pci_45
Prepare a PCIe Card For Removal
"Remove a PCIe
DOMAIN STATUS
------ ------
primary IOV
primary OCC
ldg4
Servicing PCIe Cards 151
