b.
Remove the carrier from the slot.
Carefully remove the PCIe card from the carrier.
6.
a.
Press the green tab to unlock the carrier latch, and open the top of the PCIe
card carrier (steps 1 and 2).
b.
Slide the card from the slot (step 3).
Avoid twisting, tilting, or pulling unevenly on the PCIe card, which could damage the
Caution -
carrier slot or components on the PCIe card carrier circuit board.
7.
Place the PCIe card on a grounded antistatic mat or into its antistatic packaging.
8.
Determine your next step:
If you are replacing the PCIe card, go to
■
Carrier" on page
If you are removing the PCIe card, return the card carrier to the server.
■
See
"Install a Card Carrier Into the Server" on page
"Install a PCIe Card Into a Card
158.
Remove a PCIe Card Carrier and Card From the Server
159.
Servicing PCIe Cards
157
