Switch Chassis Front Components (Sparc M7-16) - Oracle SPARC M8 Service Manual

No.
2
3
4
5
6
7
Related Information
"CMIOU Chassis Front Components" on page 20
■

Switch Chassis Front Components (SPARC M7-16)

Access these components from the front of the server. These components are not part of the
chassis. You must remove these components to access the chassis.
Description
■ Top CMIOU chassis: ROPNL2
AC inputs (1 strip, 6 outlets per CMIOU chassis)
This component is part of the power module.
■ Bottom CMIOU chassis, top to bottom:
AC5–AC0
■ Top CMIOU chassis, top to bottom: AC15–AC10
CMIOUs (8)
■ Bottom CMIOU chassis, top to bottom:
CMIOU_7–CMIOU_0
■ Top CMIOU chassis, top to bottom:
CMIOU_15–CMIOU_8
PCIe x16 carriers (up to 24 cards per CMIOU
chassis)
SPs (2), bottom CMIOU chassis, left to right
(SPARC M8-8 and SPARC M7-8 servers): SP0,SP1
SPPs (4, SPARC M7-16 server):
■ Bottom CMIOU chassis, left to right:
SPP0,SPP1
■ Top CMIOU chassis, left to right: SPP2,SPP3
PDECBs (8)
■ Bottom CMIOU chassis, top to bottom:
PDECB7–PDECB0
■ Top CMIOU chassis, top to bottom:
PDECB21–PDECB14
SP tray (1)
Switch Chassis Front Components (SPARC M7-16)
Links
"Servicing Power Modules" on page 235
"Servicing CMIOUs" on page 83
"Servicing PCIe Cards" on page 141
"Servicing SPs" on page 117
"Servicing PDECBs" on page 199
"Servicing SP Trays" on page 243
Identifying Components 23
