No.
4
Related Information
"Switch Chassis Rear Components (SPARC M7-16)" on page 25
■
Switch Chassis Rear Components (SPARC M7-16)
Access these components from the rear of the server. These components are not part of the
chassis. You must remove these components to access the chassis.
Description
■ II_SWITCH_SP (switch chassis, slot IT_14)
■ II_CMIOU_SP (bottom CMIOU chassis slot, IT_5)
Power supplies (4), top to bottom: PS9–PS6
Switch Chassis Rear Components (SPARC M7-16)
Links
"Servicing Power
Supplies" on page 165
Identifying Components
25
