Install an SP Internal Interconnect Assembly

Install an SP Internal Interconnect Assembly
Caution -
that hold the inner and outer horizontal connectors in place, handle the interconnect with care
to avoid damaging the floating connector housings. These housings can become damaged if
they loosen and catch on the chassis, which can impact your ability to install or remove the
interconnect. If you notice that these springs or the connectors are damaged, do not install the
interconnect into the chassis.
290 SPARC M8 and SPARC M7 Servers Service Manual • September 2017
If the SP internal interconnect you are installing has stirrup-shaped leaf springs
