Install a CMIOU Chassis

If you have not already done so, remove the faulty CMIOU chassis.
1.
See "Remove a CMIOU Chassis" on page
2. Determine your next step:
If you have another person to assist you, go to
■
If you are alone, go to
■
Place the chassis on a mechanical lift.
3.
4. Install the chassis into the rack and secure the chassis with the five screws that
were removed.
5. At the front of the server, install these components.
Component
Interconnects
Fan modules
At the rear of the server, install these components.
6.
Component
Power modules
PDECBs
Switch units (SPARC M7-16)
CMIOUs
Fan modules (SPARC M7-16)
SP tray
SPs
Cables
At the front of the server, install the power supplies.
7.
269.
Step 3.
Link
"Servicing Internal Interconnect Assemblies" on page 297
"Servicing External Interconnect Assemblies" on page 305
"Servicing SP Internal Interconnect Assemblies" on page 285
"Servicing Fan Modules (CMIOU Chassis)" on page 179
Link
"Servicing Power Modules" on page 235
"Servicing PDECBs" on page 199
"Servicing Switch Units" on page 189
"Servicing CMIOUs" on page 83
"Servicing Fan Modules (Switch Chassis)" on page 183
"Servicing SP Trays" on page 243
"Servicing SPs" on page 117
Ensure that you install the cables in the same slots from
which you removed them.
Install a CMIOU Chassis
Step 4.
