Install an SP Internal Interconnect Assembly
2.
From the front of the server, carefully slide the SP internal interconnect
assembly into the chassis.
Caution -
Align the assembly in the chassis and install the assembly slowly to avoid bending or otherwise
damaging them.
3.
Secure the SP internal interconnect assembly to the chassis.
a.
Tighten the captive screws on the face of the assembly.
292
SPARC M8 and SPARC M7 Servers Service Manual • September 2017
The small connector pins on the back of the assembly are susceptible to damage.
