CMIOU No.
CMIOU10
CMIOU9
CMIOU9
CMIOU9
CMIOU8
CMIOU8
CMIOU8
Related Information
"PCIe Card Slot Configuration and Numbering" on page 142
■
"PCIe Card Installation Order Guidelines" on page 145
■

Supported PCIe Card Carriers and PCIe Cards

SPARC M8 and SPARC M7 servers support the use of only PCIe x16 hot-plug card carriers,
which are physically labeled with "x16 CAR" on the faceplate. PCIe x8 card carriers from
earlier generations of Oracle servers, which are labeled with "CAR" on the faceplate, are not
supported for use in SPARC M8 and M7 servers. PCIe x8 and PCIe x16 cards are supported for
use in these servers.
Related Information
■
https://community.oracle.com/community/server_%26_storage_systems/systems-
io/sparc-servers
"PCIe Card Slot Configuration and Numbering" on page 142
■
"Understanding PCIe Card Device and Service Paths" on page 143
■

PCIe Card Installation Order Guidelines

These sections provide detailed information about the order in which to install PCIe cards in the
server.
Device Path
/pci@335/pci@1
/pci@32e/pci@1
/pci@32d/pci@1
/pci@330/pci@1
/pci@329/pci@1
/pci@328/pci@1
/pci@32b/pci@1
Supported PCIe Card Carriers and PCIe Cards
Service Path
/SYS/CMIOU10/PCIE1
/SYS/CMIOU9/PCIE3
/SYS/CMIOU9/PCIE2
/SYS/CMIOU9/PCIE1
/SYS/CMIOU8/PCIE3
/SYS/CMIOU8/PCIE2
/SYS/CMIOU8/PCIE1
BUS Name
pci_53
pci_46
pci_45
pci_48
pci_41
pci_40
pci_43
Servicing PCIe Cards 145
