SER MGT and NET MGT Port Locations and Numbering

The NET MGT and SER MGT ports are accessible on the SPs and SPPs from the rear of the
server.
Refer to the
cabling the network management ports on your server.
Note -
SPs do not have a label.
No.
1–4
5–8
Related Information
"Servicing SPs" on page 117
■
"CMIOU Chassis Rear Components" on page 21
■
"Switch Chassis Rear Components (SPARC M7-16)" on page 25
■
SPARC M8 and SPARC M7 Servers Installation Guide
The SPARC M8 SP has a SPARC M8 label on its left extraction lever. The SPARC M7
Description
SER MGT ports (0–3)
NET MGT ports (0–3)
SER MGT and NET MGT Port Locations and Numbering
Links
The serial ports enable you to connect directly to the SPs and
SPPs.
The Ethernet ports enable you to connect the server to your local
network so that you can manage the server from a remote location.
for information about
