Avoid twisting, tilting, or pushing unevenly on the PCIe card as you insert it into
Caution -
the carrier, which could damage the carrier slot or components on the PCIe card carrier circuit
board. The card's connector must be fully seated in the carrier's slot before you attempt to close
the top cover.
If the PCIe card includes a mounting screw, do not use the mounting screw. The carrier
Note -
does not accept mounting screws.
Close the top of the carrier (panel 2).
b.
The green latch should click into place. If the top is difficult to close, verify that the notch
of the card bracket or filler panel fits around the guide post.
Install the card carrier into the server.
4.
See "Install a Card Carrier Into the Server" on page
Related Information
"Remove a PCIe Card Carrier and Card From the Server" on page 156
■

Install a Card Carrier Into the Server

Install only PCIe x16 hot-plug card carriers, which are physically labeled with "x16 CAR" on
the faceplate, in SPARC M8 and M7 servers. Do not install PCIe x8 card carriers, which are
labeled with "CAR" on the faceplate, from earlier generations of Oracle servers. See
PCIe Card Carriers and PCIe Cards" on page
Ensure that you have already taken antistatic measures.
1.
See "Prevent ESD Damage" on page
2. Ensure that the primary domain is at the Oracle Solaris prompt.
Installing a PCIe card carrier while the primary domain is at the Open Boot prompt is not
Note -
supported.
159.
145.
61.
Install a Card Carrier Into the Server
"Supported
Servicing PCIe Cards 159
