3 Parameter Description

3.6 Main Menu - Limits/Warnings - Group 4

3.6.1 4-** Limits and Warnings
Parameter group for configuring limits and warnings.
3
3.6.2 4-1* Motor Limits
Define torque, current and speed limits for the motor, and the reaction of the frequency converter when the limits are exceeded.
A limit may generate a message on the display. A warning will always generate a message on the display or on the fieldbus. A monitoring function may
initiate a warning or a trip, upon which the frequency converter will stop and generate an alarm message.
4-10 Motor Speed Direction
Option:
[0] * Clockwise
[2] * Both directions
NB!
The setting in par.4-10
4-11 Motor Speed Low Limit [RPM]
Range:
0 RPM* [0 - par. 4-13 RPM]
4-12 Motor Speed Low Limit [Hz]
Range:
Application [0 - par. 4-14 Hz]
Depend-
ent*
4-13 Motor Speed High Limit [RPM]
Range:
1500. RPM* [par. 4-11 - 60000. RPM]
NB!
The output frequency value of the frequency converter must not exceed a value higher than 1/10 of the switching frequency.
64
Function:
Selects the motor speed direction required.
Use this parameter to prevent unwanted reversing.
Only operation in clockwise direction will be allowed.
Operation in both clockwise and anti-clockwise direction will be allowed.
Motor Speed Direction has impact on the Flying Start in par.1-73
Function:
Enter the minimum limit for motor speed. The Motor Speed Low Limit can be set to correspond to
the manufacturer's recommended minimum motor speed. The Motor Speed Low Limit must not
exceed the setting in par.4-13
Function:
Enter the minimum limit for motor speed. The Motor Speed Low Limit can be set to correspond to
the minimum output frequency of the motor shaft. The Speed Low Limit must not exceed the setting
Motor Speed High Limit [Hz]
in par.4-14
Function:
Enter the maximum limit for motor speed. The Motor Speed High Limit can be set to correspond to
the manufacturer's maximum rated motor. The Motor Speed High Limit must exceed the setting in
Motor Speed Low Limit [RPM]
par.4-11
Motor Speed Low Limit [Hz]
4-12
and depending on default settings dependant on global location.
MG.11.N1.02 - VLT
ADAP-KOOL
Flying Start
Motor Speed High Limit [RPM]
.
.
Motor Speed Low Limit [RPM]
. Only par.4-11
will be displayed depending on other parameters in the Main Menu
