3 Parameter Description
[3]
Select set-up 2
[4]
Select set-up 3
[5]
Select set-up 4
[10]
Select preset ref 0
[11]
Select preset ref 1
3
[12]
Select preset ref 2
[13]
Select preset ref 3
[14]
Select preset ref 4
[15]
Select preset ref 5
[16]
Select preset ref 6
[17]
Select preset ref 7
[18]
Select ramp 1
[19]
Select ramp 2
[22]
Run
[23]
Run reverse
[24]
Stop
[26]
DC Brake
[27]
Coast
[28]
Freeze output
[29]
Start timer 0
[30]
Start timer 1
[31]
Start timer 2
[32]
Set digital out A low
[33]
Set digital out B low
[34]
Set digital out C low
[35]
Set digital out D low
[36]
Set digital out E low
[37]
Set digital out F low
[38]
Set digital out A high
[39]
Set digital out B high
[40]
Set digital out C high
[41]
Set digital out D high
[42]
Set digital out E high
[43]
Set digital out F high
[50]
Night Action
[51]
Day Action
116
Changes the active set-up (par.0-10
Changes the active set-up (par.0-10
Active Set-up
Changes the active set-up (par.0-10
other set-up commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 0.
Selects preset reference 1.
Selects preset reference 2.
Selects preset reference 3.
Selects preset reference 4.
Selects preset reference 5.
Selects preset reference 6.
Selects preset reference 7. If the active preset reference is changed, it will merge with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects ramp 1
Selects ramp 2
Issues a start command to the frequency converter.
Issues a start reverse command to the frequency converter.
Issues a stop command to the frequency converter.
Issues a DC stop command to the frequency converter.
The frequency converter coasts immediately. All stop commands including the coast command stop
the SLC.
Freezes the output frequency of the frequency converter.
SL Controller Timer
Starts timer 0, see par.13-20
SL Controller Timer
Starts timer 1, see par.13-20
Starts timer 2, see par.13-20
SL Controller Timer
Any output with 'digital output 1' selected is low (off).
Any output with 'digital output 2' selected is low (off).
Any output with 'digital output 3' selected is low (off).
Any output with 'digital output 4' selected is low (off).
Any output with 'digital output 5' selected is low (off).
Any output with 'digital output 6' selected is low (off).
Any output with 'digital output 1' selected is high (closed).
Any output with 'digital output 2' selected is high (closed).
Any output with 'digital output 3' selected is high (closed).
Any output with 'digital output 4' selected is high (closed).
Any output with 'digital output 5' selected is high (closed).
Any output with 'digital output 6' selected is high (closed).
MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
®
ADAP-KOOL
Drive Programming Guide
Active Set-up
) to '2'.
Active Set-up
) to '3'.
) to '4'. If the set-up is changed, it will merge with
for further description.
for further description.
for further description.
