Danfoss ADAP-KOOL Drive Programming Manual page 52

3 Parameter Description
[3] Start speed cw
3
[5] VVC+/Flux clockwise
1-73 Flying Start
Option:
[0] * Disabled
[1] Enabled
1-74 Start Speed [RPM]
Range:
0 RPM* [0 - 600 RPM]
1-75 Start Speed [Hz]
Range:
0 Hz* [0.0 - 500.0 Hz]
1-76 Start Current
Range:
0.00 A* [0.00 - par. 1-24 A]
1-77 Compressor Start Max Speed [rpm]
Range:
0 rpm* [0.0 - max output speed]
52
Only possible with VVC+.
Connect the function described in par. 1-74
start delay time.
Regardless of the value applied by the reference signal, the output speed applies the setting of the
start speed in par. 1-74 or par. 1-75 and the output current corresponds to the setting of the start
Start Current
current in par. 1-76 . This function is typically used in hoisting applications without
counterweight and especially in applications with a Cone-motor, where the start is clockwise, fol-
lowed by rotation in the reference direction.
for the function described in par. 1-74 only (
is calculated automatically. This function uses the start speed in the start delay time only. Regardless
of the value set by the reference signal, the output speed equals the setting of the start speed in
Start speed/current clockwise
par. 1-74.
Start speed/current in reference direction
hoisting applications.
tions with counterweight and horizontal movement.
Function:
This function makes it possible to catch a motor which is spinning freely due to a mains drop-out.
Flying Start
When par.1-73 is enabled, par. 1-71
Search direction for flying start is linked to the setting in par.4-10
Clockwise
[0]: Flying start search in clockwise direction. If not successful, a DC brake is carried out.
Both Directions
[2]: The flying start will first make a search in the direction determined by the last
reference (direction). If not finding the speed it will make a search in the other direction. If not
successful, a DC brake will be activated in the time set in par.2-02
take place from 0 Hz.
Disable
Select [0] if this function is not required
Enable
Select [1] to enable the frequency converter to "catch" and control a spinning motor.
Function:
Set a motor start speed. After the start signal, the output speed leaps to set value. Set the start
Start Function
function in par. 1-72 to [3], [4] or [5], and set a start delay time in par. 1-71
Delay
.
Function:
Set a motor start speed. After the start signal, the output speed leaps to set value. Set the start
Start Function
function in par. 1-72 to [3], [4] or [5], and set a start delay time in par. 1-71
Delay
.
Function:
Some motors, e.g. cone rotor motors, need extra current/starting speed to disengage the rotor. To
obtain this boost, set the required current in par.1-76
[RPM] Start Function
. Set par. 1-72
Delay .
This parameter can be used for hoist applications (cone rotor).
Function:
The parameter enables "High Starting Torque". This is a function, where the Current Limit and
Torque Limit are ignored during start of the motor. The time, from the start signal is given until the
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
®
ADAP-KOOL Drive Programming Guide
Start Speed (RPM) and par. 1-76
Start speed in the start delay time
VVCplus/Flux clockwise
[3] and [5] are typically used in
[4] is particularly used in applica-
Start Delay
has no function.
Motor Speed Direction
DC Braking Time
Start Current
. Set par.1-74
to [3] or [4], and set a start delay time in par. 1-71
Start Current in the
). The start current
.
. Start will then
Start
Start
Start Speed
Start
