3 Parameter Description
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
-1.000 N/A* [-999999.999 - 999999.999 N/A]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
3
Application [-999999.999 - 999999.999 N/A]
Depend-
ent*
6-26 Terminal 54 Filter Time Constant
Range:
0.001 s* [0.001 - 10.000 s]
6-27 Terminal 54 Live Zero
Option:
[0] Disabled
[1] * Enabled
3.8.5 6-3* Analog Input 3 MCB 101
Parameter group for configuring the scale and limits for analog input 3 (X30/11) placed on option module MCB 101.
6-30 Terminal X30/11 Low Voltage
Range:
0.07 V* [0.00 - par. 6-31 V]
6-31 Terminal X30/11 High Voltage
Range:
10.00 V* [par. 6-30 - 10.00 V]
6-34 Term. X30/11 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
6-35 Term. X30/11 High Ref./Feedb. Value
Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*
88
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current value set in
Terminal 54 Low Voltage
par.6-20 and par.6-22
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
Terminal 54 High Voltage
par.6-21 and par.6-23
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
electrical noise in terminal 54. A high time constant value improves dampening but also increases
the time delay through the filter.
This parameter cannot be adjusted while the motor is running.
Function:
This parameter makes it possible to disable the Live Zero monitoring. E.g. to be used if the analog
outputs are used as part of a de-central I/O system (e.g. when not as part of any frequency con-
verter related control functions, but feeding a Building Management System with data).
Function:
Sets the analog input scaling value to correspond to the low reference/feedback value (set in par.
Term. X30/11 Low Ref./Feedb. Value
6-34
Function:
Sets the analog input scaling value to correspond to the high reference/feedback value (set in par.
Term. X30/11 High Ref./Feedb. Value
6-35
Function:
Sets the analog input scaling value to correspond to the low voltage value (set in par.6-30
X30/11 Low Voltage
).
Function:
Sets the analog input scaling value to correspond to the high voltage value (set in par.6-31
X30/11 High Voltage ).
