3 Parameter Description
[196] Fire Mode
[197] Fire Mode was act.
[198] Drive Bypass
3
[199] Injection Control
The below setting options are all related to the Cascade Controller.
Wiring diagrams and settings for parameter, see group 25-** for more details.
[200] Full Capacity
[201] Compressor 1 Running
[202] Compressor 2 Running
[203] Compressor 3 Running
Setting in Par. 5-3*
[201] Compressor 1 Running
[202] Compressor 2 Running
[203] Compressor 3 Running
5-30 Terminal 27 Digital Output
Option:
[0] * No operation
5-31 Terminal 29 Digital Output
Option:
[0] * No operation
5-32 Term X30/6 Digi Out (MCB 101)
Option:
[0] * No operation
5-33 Term X30/7 Digi Out (MCB 101)
Option:
[0] * No operation
3.7.5 5-4* Relays
Parameters for configuring the timing and the output functions for the relays.
5-40 Function Relay
Select options to define the function of the relays.
The selection of each mechanical relay is realised in an array parameter.
76
The frequency converter is operating in Fire Mode. See 24-0*
The frequency converter has been operating in Fire Mode, but is now back in normal operation.
To be used as signal for activating an external electromechanical bypass switching the motor direct
Drive Bypass
on line. See 24-1* .
If enabling the Drive Bypass Function, the frequency converter is no longer Safety
Certified (for using the Safe Stop in versions where included).
Indicates that the digital output is used for providing Injection ON-OFF signal. A low voltage on the
selected digital output indicates Injection OFF, while high voltage indicates Injection ON.
All pumps running and at full speed
One or more of the compressors controlled by the Cascade Controller are running. The function will
also depend on the setting of in Fixed Lead Compressor
refers to the compressor controlled by relay RELAY1 etc. If set to
compressor controlled by the frequency converter only (without any of the build in relays involved)
and Compressor 2 to the compressor controlled by the relay RELAY1. See below table:
See [201]
See [201]
[0] No
Controlled by RELAY1
Controlled by RELAY2
Controlled by RELAY3
Function:
Functions are described under 5-3*
Function:
Functions are described under 5-3*
Function:
This parameter is active when option module MCB 101 is mounted in the frequency converter.
Functions are described under 5-3*
Function:
This parameter is active when option module MCB 101 is mounted in the frequency converter.
Functions are described under 5-3*
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
®
ADAP-KOOL Drive Programming Guide
Fire Mode
.
, par. 25-06. If set to
Yes [1]Compressor 1 refers to the
Setting in Par. 25-06
[1] Yes
Frequency Converter controlled
Controlled by RELAY1
Controlled by RELAY2
No [0] Compressor 1
