3 Parameter Description
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
3
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
21-11 Ext. 1 Minimum Reference
Range:
0.000 Ex- [-999999.999 - par. 21-12 Ex-
tPID1Unit* tPID1Unit]
21-12 Ext. 1 Maximum Reference
Range:
100.000 Ex- [par. 21-11 - 999999.999 Ex-
tPID1Unit* tPID1Unit]
NB!
Always set the desired value for par.21-12
160
Function:
Select the minimum for the Closed Loop 1 Controller.
Function:
Select the maximum for the Closed Loop 1 Controller.
The dynamics of the PID controller will depend on the value set in this parameter. Please see also
Ext. 1 Proportional Gain
par.21-21 .
Ext. 1 Maximum Reference
before setting the values for the PID controller in par. 20-9*.
