3 Parameter Description
21-54 Ext. 3 Feedback Source
Option:
[0] * No function
[1] Analog input 53
[2] Analog input 54
3
[3] Pulse input 29
[4] Pulse input 33
[7] Analog input X30/11
[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
21-55 Ext. 3 Setpoint
Range:
0.000 Ex- [par. 21-51 - par. 21-52 Ex-
tPID3Unit* tPID3Unit]
21-57 Ext. 3 Reference [Unit]
Range:
0.000 Ex- [-999999.999 - 999999.999 Ex-
tPID3Unit* tPID3Unit]
21-58 Ext. 3 Feedback [Unit]
Range:
0.000 Ex- [-999999.999 - 999999.999 Ex-
tPID3Unit* tPID3Unit]
21-59 Ext. 3 Output [%]
Range:
0 %* [0 - 100 %]
3.16.8 21-6* Closed Loop 3 PID
Configure the Closed Loop 3 PID Controller.
21-60 Ext. 3 Normal/Inverse Control
Option:
[0] * Normal
[1] Inverse
21-61 Ext. 3 Proportional Gain
Range:
0.01 N/A* [0.00 - 10.00 N/A]
168
Function:
Ext. 1 Feedback Source
See par.21-14
Function:
Ext. 1 Setpoint
See par.21-15 for details.
Function:
See par.21-17 Ext. 1 Reference [Unit]
Function:
See par.21-18 Ext. 1 Feedback [Unit]
Function:
Ext. 1 Output [%]
See par.21-19 for details.
Function:
Ext. 1 Normal/Inverse Control
See par.21-20
Function:
Ext. 1 Proportional Gain
See par.21-21
