ADAP-KOOL
®
Drive Programming Guide
Contents
0-** Operation and Display
1-** Load / Motor
MG.11.N1.02 - VLT
®
is a registered Danfoss trademark
Contents
3
3
4
4
10
15
15
15
31
31
31
31
46
56
57
64
68
85
95
103
118
126
134
142
145
157
170
180
180
185
200
209
218
223
223
223
224
226
