3 Parameter Description
[121] Lead Compressor Alternation
[130 - 132] Compressor 1 Interlock - Compres-
sor 3 Interlock
3
[139] Compressor 1 Inverse Interlock
[140] Compressor 2 Inverse Interlock
[141] Compressor 3 Inverse Interlock
5-10 Terminal 18 Digital Input
Option:
[8] * Start
5-11 Terminal 19 Digital Input
Option:
[10] * Reversing
5-12 Terminal 27 Digital Input
Option:
[2] * Coast inverse
5-13 Terminal 29 Digital Input
Option:
[0] * No operation
5-14 Terminal 32 Digital Input
Option:
[39] * Day/Night control
5-15 Terminal 33 Digital Input
Option:
[0] * No operation
72
Forces alternation of the lead Compressor in a Cascade Controller.
par. 25-50, must be set to either At Command
Event , par. 25-51, can be set to any of the four options.
For all 3 setting options below, par. 25-10, Compressor Interlock, must be set to
will also depend on the setting in par. 25-06, Fixed Lead Compressor. If set to
pressor 1 refers to the Compressor controlled by relay RELAY1 etc. If set to
refers to the Compressor controlled by the frequency converter only (without any of the build in
relays involved) and Compresso r2 to the Compressor controlled by the relay RELAY1. Variable speed
Compressor (lead) cannot be interlocked.
See below table:
Setting in Par. 5-1*
[130] Compressor 1 Interlock Controlled by RELAY1 (only if
[131] Compressor2 Interlock
[132] Compressor3 Interlock
Interlocks compressor 1 of the Pack Controller when digitally low and issues Warning [W219]. When
inversely interlocked, compressor 1 (the lead compressor) is staging according to the Fixed Speed
Neutral Zone (par. 25-23).
Interlocks compressor 2 of the Pack Controller when digitally low and issues Warning [W219].
Interlocks compressor 3 of the Pack Controller when digitally low and issues Warning [W219]..
Function:
Functions are described under 5-1*
Function:
Functions are described under 5-1*
Function:
Functions are described under 5-1*
Function:
Select the function from the available digital input range and the additional options [60], [61], [63]
and [64]. Counters are used in Smart Logic Control functions.
Functions are described under 5-1*
Function:
Select the function from the available digital input range and the additional options [60], [61], [63]
and [64]. Counters are used in Smart Logic Control functions.
Functions are described under 5-1*
Function:
Select the function from the available digital input range and the additional options [60], [61], [63]
and [64]. Counters are used in Smart Logic Control functions.
Functions are described under 5-1*
