ADAP-KOOL Drive Programming Guide
21-34 Ext. 2 Feedback Source
Option:
[0] * No function
[1] Analog input 53
[2] Analog input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog input X30/11
[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
21-35 Ext. 2 Setpoint
Range:
0.000 Ex- [par. 21-31 - par. 21-32 Ex-
tPID2Unit* tPID2Unit]
21-37 Ext. 2 Reference [Unit]
Range:
0.000 Ex- [-999999.999 - 999999.999 Ex-
tPID2Unit* tPID2Unit]
21-38 Ext. 2 Feedback [Unit]
Range:
0.000 Ex- [-999999.999 - 999999.999 Ex-
tPID2Unit* tPID2Unit]
21-39 Ext. 2 Output [%]
Range:
0 %* [0 - 100 %]
3.16.6 21-4* Closed Loop 2 PID
Configure the Closed Loop 2 PID Controller.
21-40 Ext. 2 Normal/Inverse Control
Option:
[0] * Normal
[1] Inverse
21-41 Ext. 2 Proportional Gain
Range:
0.01 N/A* [0.00 - 10.00 N/A]
Function:
Ext. 1 Feedback Source
See par.21-14
Function:
Ext. 1 Setpoint
See par.21-15 for details.
Function:
See par.21-17 Ext. 1 Reference [Unit]
Function:
See par.21-18 Ext. 1 Feedback [Unit]
Function:
Ext. 1 Output [%]
See par.21-19 for details.
Function:
Ext. 1 Normal/Inverse Control
See par.21-20
Function:
Ext. 1 Proportional Gain
See par.21-21
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
for details.
, Ext. 1 Reference [Unit] , for details.
for details.
for details.
for details.
