ADAP-KOOL Drive Programming Guide
[0] * Not linked
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
0-13 Readout: Linked Set-ups
Array [5]
Range:
0 N/A* [0 - 255 N/A]
0-14 Readout: Prog. Set-ups / Channel
Range:
0 N/A* [-2147483648 - 2147483647 N/A]
3.2.4 0-2* LCP Display
Define the variables displayed in the Graphical Local Control Panel.
NB!
Please refer to par.0-37
texts
0-20 Display Line 1.1 Small
Option:
[0] None
[37] Display Text 1
[38] Display Text 2
Function:
View a list of all the set-ups linked by means of par.0-12
one index for each parameter set-up. The parameter value displayed for each index represents
which setups are linked to that parameter setup.
Index
0
1
2
3
4
Table 3.2: Example: Set-up 1 and Set-up 2 are linked
Function:
View the setting of par.0-11
channels. When the number is displayed in hex, as it is in the LCP, each number represents one
channel.
Numbers 1-4 represent a set-up number; 'F' means factory setting; and 'A' means active set-up.
The channels are, from right to left: LCP, FC bus, USB, HPFB1.5.
Example: The number AAAAAA21h means that the FC bus selected Set-up 2 in par.0-11
ming Set-up
, the LCP selected Set-up 1 and all others used the active set-up.
Display Text 1 Display Text 2
, par.0-38
Function:
Select a variable for display in line 1, left position. Default setting is application dependent.
No display value selected
Enables an individual text string to be written, for display in the LCP or to be read via serial com-
munication.
Enables an individual text string to be written, for display in the LCP or to be read via serial com-
munication.
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
This Set-up Linked to
LCP value
{0}
{1,2}
{1,2}
{3}
{4}
Programming Set-up
for each of the four different communication
Display Text 3
and par.0-39 for information on how to write display
3 Parameter Description
3
. The parameter has
Program-
