Danfoss ADAP-KOOL Drive Programming Manual page 23

®
ADAP-KOOL Drive Programming Guide
NB!
Stop the motor before performing this operation.
You can now connect the LCP to another frequency converter and copy the parameter settings to this frequency converter as well.
Data transfer from LCP to frequency converter:
1. Go to par.0-50 LCP Copy
2. Press the [OK] key
3. Select "All from LCP"
4. Press the [OK] key
The parameter settings stored in the LCP are now transferred to the frequency converter indicated by the progress bar. When 100% is reached, press
[OK].
NB!
Stop the motor before performing this operation.
2.1.4 Parameter Set-Up
The frequency converter can be used for practically all assignments, thus offering a significant number of parameters. The series offers a choice between
two programming modes - the Quick Menu mode and the Main Menu mode.
The latter provides access to all parameters. The former takes the user through a few parameters making it possible to program the majority of
ADAP-KOOL Drive AKD 102 applications.
Regardless of the mode of programming, you can change a parameter both in the Quick Menu mode and in the Main Menu mode.
2.1.5 Quick Menu Mode
Parameter Data
The graphical display (GLCP) provides access to all parameters listed un-
der the Quick Menus. To set parameters using the [Quick Menu] button
- enter or change parameter data or settings in accordance with the fol-
lowing procedure:
1. Press Quick Menu button
▲ ▼
2.
Use the [ ] and [ ] buttons to find the parameter you want to
change
3. Press [OK]
▲ ▼
4.
Use [ ] and [ ] buttons to select the correct parameter setting
5. Press [OK]
6. To move to a different digit within a parameter setting, use the
◀ ▶
[ ] and [ ] buttons
7. Highlighted area indicates digit selected for change
8. Press [Cancel] button to disregard change, or press [OK] to ac-
cept change and enter the new setting
Select [My Personal Menu] to display only the parameters, which have been pre-selected and programmed as personal parameters. For example, an AHU
or pump OEM may have pre-programmed these to be in My Personal Menu during factory commissioning to make on-site commissioning / fine tuning
simpler. These parameters are selected in par. 0-25 Personal Menu . Up to 20 different parameters can be programmed in this menu.
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
Example of Changing Parameter Data
22-60, Broken Belt Function
Assume parameter
you want to monitor the fan-belt condition - non- broken or broken -
according to the folowing procedure:
1. Press Quick Menu key
2.
Choose Function Setups with the [
3. Press [OK]
4.
Choose Application Settings with the [
5. Press [OK]
6. Press [OK] again for Fan Functions
7. Choose Broken Belt Function by pressing [OK]
▼
8.
With [ ] button, choose [2] Trip
The frequency converter will now trip if a broken fan-belt is detected.
2 How to Programme
2
is set to [Off]. However,
▼
] button
▼
] button
23
