3 Parameter Description
3.8.7 6-5* Analog Output 1
Parameters for configuring the scaling and limits for analog output 1, i.e. Terminal 42. Analog outputs are current outputs: 0/4 – 20 mA. Common terminal
(terminal 39) is the same terminal and has the same electrical potential for analog common and digital common connection. Resolution on analog output
is 12 bit.
6-50 Terminal 42 Output
Option:
3
[0] No operation
[100] * Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[130] Output freq. 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.% lim 4-20 mA
[135] Torq.% nom 4-20mA
[136] Power 4-20mA
[137] Speed 4-20mA
[138] Torque 4-20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl t.o. 4-20mA
[143] Ext. CL 1 4-20mA
[144] Ext. CL 2 4-20mA
[145] Ext. CL 3 4-20mA
[150] Max Out Fr 4-20 mA
90
Function:
Select the function of Terminal 42 as an analog current output. A motor current of 20 mA corre-
sponds to I .
max
: 0 - 100 Hz, (0-20 mA)
: Minimum reference - Maximum reference, (0-20 mA)
Maximum Reference/Feedb.
: -200% to +200% of par. 20-14
Torque Limit Motor Mode
: 0 - Torque limit (par.4-16
: 0 - Motor rated torque, (0-20 mA)
: 0 - Motor rated power, (0-20 mA)
: 0 - Speed High Limit (par.4-13 Motor Speed High Limit [RPM]
[Hz] ), (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100 Hz
: Minimum Reference - Maximum Reference
: -200% to +200% of par. 20-14 Maximum Reference/Feedb.
: 0 - Inverter Max. Current (par.16-37
Torque Limit Motor Mode
: 0 - Torque limit (par.4-16
: 0 - Motor rated torque
: 0 - Motor rated power
: 0 - Speed High Limit (4-13 and 4-14)
: 0 - 100%, (0-20 mA)
: 0 - 100%
: 0 - 100%, (0-20 mA)
: 0 - 100%
: 0 - 100%
: 0 - 100%
: 0 - 100%
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
®
ADAP-KOOL Drive Programming Guide
, (0-20 mA)
), (0-20 mA)
and par.4-14
Inv. Max. Current
)
)
Motor Speed High Limit
