ADAP-KOOL Drive Programming Guide
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
21-51 Ext. 3 Minimum Reference
Range:
0.000 Ex- [-999999.999 - par. 21-52 Ex-
tPID3Unit* tPID3Unit]
21-52 Ext. 3 Maximum Reference
Range:
100.000 Ex- [par. 21-51 - 999999.999 Ex-
tPID3Unit* tPID3Unit]
21-53 Ext. 3 Reference Source
Option:
[0] * No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
Function:
See par.21-11 Ext. 1 Minimum Reference
Function:
Ext. 1 Maximum Reference
See par.21-12
Function:
Ext. 1 Reference Source
See par.21-13
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
for details.
for details.
for details.
