3 Parameter Description
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
3
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
106
Use the result of comparator 1 in the logic rule.
Use the result of comparator 2 in the logic rule.
Use the result of comparator 3 in the logic rule.
Use the result of logic rule 0 in the logic rule.
Use the result of logic rule 1 in the logic rule.
Use the result of logic rule 2 in the logic rule.
Use the result of logic rule 3 in the logic rule.
Use the result of timer 0 in the logic rule.
Use the result of timer 1 in the logic rule.
Use the result of timer 2 in the logic rule.
Use the value of DI18 in the logic rule (High = TRUE).
Use the value of DI19 in the logic rule (High = TRUE).
Use the value of DI27 in the logic rule (High = TRUE).
Use the value of DI29 in the logic rule (High = TRUE).
Use the value of DI32 in the logic rule (High = TRUE).
Use the value of DI33 in the logic rule (High = TRUE).
This event is TRUE if the frequency converter is started by any means (either via digital input,
fieldbus or other).
This event is TRUE if the frequency converter is stopped or coasted by any means (either via digital
input, fieldbus or other).
This event is TRUE if the frequency converter is tripped (but not trip-locked) and the reset button
is pressed.
This event is TRUE if the frequency converter is tripped (but not trip-locked) and an Automatic Reset
is issued.
This event is TRUE if the OK key on the LCP is pressed.
This event is TRUE if the Reset key on the LCP is pressed.
This event is TRUE if the Left key on the LCP is pressed.
This event is TRUE if the Right key on the LCP is pressed.
This event is TRUE if the Up key on the LCP is pressed.
This event is TRUE if the Down key on the LCP is pressed.
Use the result of comparator 4 in the logic rule.
Use the result of comparator 5 in the logic rule.
Use the result of logic rule 4 in the logic rule.
Use the result of logic rule 5 in the logic rule.
Use the result of timer 3 in the logic rule.
Use the result of timer 4 in the logic rule.
Use the result of timer 5 in the logic rule.
Use the result of timer 6 in the logic rule.
Use the result of timer 7 in the logic rule.
