Danfoss ADAP-KOOL Drive Programming Manual page 214

3 Parameter Description
26-31 Terminal X42/5 High Voltage
Range:
10.00 V* [par. 6-30 - 10.00 V]
26-34 Term. X42/5 Low Ref./Feedb. Value
Range:
3
0.000 N/A* [-999999.999 - 999999.999 N/A]
26-35 Term. X42/5 High Ref./Feedb. Value
Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*
26-36 Term. X42/5 Filter Time Constant
Range:
0.001 s* [0.001 - 10.000 s]
26-37 Term. X42/5 Live Zero
Option:
[0] Disabled
[1] * Enabled
26-40 Terminal X42/7 Output
Option:
[0] * No operation
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
214
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par.26-35
Function:
Enter the analog input scaling value that corresponds to the low voltage value set in par.
Terminal X42/5 Low Voltage
26-30 .
Function:
Enter the analog input scaling value that corresponds to the high voltage value set in par.
26-21 Terminal X42/3 High Voltage .
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
noise in terminal X42/5. A high time constant value improves dampening but also increases the time
delay through the filter. This parameter cannot be adjusted while the motor is running.
Function:
This parameter makes it possible to enable the Live Zero monitoring. E.g. where the analog input
is a part of the frequency converter control, rather than being used as part of a decentral I/O system,
such as a Building Management System.
Function:
Set the function of terminal X42/7 as an analog voltage output.
: 0 - 100 Hz, (0-20 mA)
: Minimum reference - Maximum reference, (0-20 mA)
Maximum Reference/Feedb.
: -200% to +200% of par. CL-14
Torque Limit Motor Mode
: 0 - Torque limit (par.4-16
: 0 - Motor rated torque, (0-20 mA)
: 0 - Motor rated power, (0-20 mA)
: 0 - Speed High Limit (par.4-13 Motor Speed High Limit [RPM]
[Hz]
), (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
®
ADAP-KOOL Drive Programming Guide
Term. X42/5 High Ref./Feedb. Value
, (0-20 mA)
), (0-20 mA)
and par.4-14
.
Motor Speed High Limit
