3 Parameter Description
25-80 Pack Status
Option:
Disabled
Emergency
Off
3
In Open Loop
Frozen
Jogging
Running
Running FSBW
Staging
Destaging
Lead Not Set
25-81 Compressor Status
Option:
[X] Disabled
[O] Off
[D] Running on Frequency Converter
[R] Running on Mains
25-82 Lead Compressor
Option:
0 N/A
25-83 Relay Status
Array [2]
On
Off
25-84 Compressor ON Time
208
Function:
Read out of the status of the Pack Controller.
Pack Controller is disabled ( Pack Controller
All compressors have been stopped by means of a Coast/Coast inverse or an External Interlock
command applied to the frequency converter.
All compressors have been stopped by means of a Stop command applied to the frequency con-
verter.
Configuration Mode
, Par. 1-00, has been set for Open Loop. All fixed speed compressors are stop-
ped. The variable speed compressor will continue to run.
Staging/destaging of compressors has been locked and reference locked.
All fixed speed compressors are stopped. When stopped, the variable speed compressor will run at
jog speed.
A Start command is applied to the frequency converter and the Pack controller is controlling the
compressors.
The frequency converter is tripped off and the Pack Controller is controlling the fixed speed com-
Fixed Speed Bandwidth
pressors based on
The Pack Controller is staging fixed speed compressors.
The Pack Controller is destaging fixed speed compressors.
No compressor available to be assigned as variable speed compressor.
Function:
Compressor Status shows the status for the number of compressors selected in
pressors
, par. 25-01. It is a readout of the status for each of the compressors showing a string,
which consists of compressor number and the current status of the compressor.
Example: Readout is with the abbreviation like "1:D 2:O" This means that compressor 1 is running
and speed controlled by the frequency converter and compressor 2 is stopped.
The compressor is interlocked either via
input programmed for Compressor (number on compressor) Interlock in
Can only refer to fixed speed compressors.
Stopped by the cascade controller (but not interlocked).
Variable speed compressor, regardless if connected directly or controlled via relay in the frequency
converter.
Running on mains. Fixed speed compressor running.
Function:
Readout parameter for the actual variable speed compressor in the system. The Lead Compressor
parameter is updated to reflect the current variable speed compressor in the system when an al-
ternation takes place. If no lead compressor is selected (Cascade Controller disabled or all com-
pressors interlocked) the display will show NONE.
Read out of the status for each of the relays assigned to control the compressors. Every element in
the array represents a relay. If a relay is activated, the corresponding element is set to "On". If a
relay is deactivated, the corresponding element is set to "Off".
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
®
ADAP-KOOL Drive Programming Guide
, Par. 25-00).
, par. 25-22.
Compressor Interlock , par. 25-19, or signal on a digital
Digital Inputs
Number of Com-
, par. 5-1*.
