Danfoss ADAP-KOOL Drive Programming Manual page 149

®
ADAP-KOOL Drive Programming Guide
20-20 Feedback Function
Option:
[0] Sum
[1] Difference
[2] Average
[3] * Minimum
[4] Maximum
[5] Multi Setpoint Min
Function:
This parameter determines how the three possible feedbacks will be used to control the output
frequency of the frequency converter.
Sum
[0] sets up the PID Controller to use the sum of Feedback 1, Feedback 2 and Feedback 3 as
the feedback.
NB!
Any unused feedbacks must be set to
Source , par.20-03
The sum of Setpoint 1 and any other references that are enabled (see par. group 3-1*) will be used
as the PID Controller's set-point reference.
Difference
[1] sets up the PID controller to use the difference between Feedback 1 and Feedback
2 as the feedback. Feedback 3 will not be used with this selection. Only Setpoint 1 will be used. The
sum of Setpoint 1 and any other references that are enabled (see par. group 3-1*) will be used as
the PID controller's set-point reference.
Average [2] sets up the PID Controller to use the average of Feedback 1, Feedback 2 and Feedback
3 as the feedback.
NB!
Any unused feedbacks must be set to
Source , par.20-03
of Setpoint 1 and any other references that are enabled (see par. group 3-1*)
will be used as the PID Controller's set-point reference.
Minimum
[3] sets up the PID Controller to compare Feedback 1, Feedback 2 and Feedback 3 and
use the lowest value as the feedback.
NB!
Any unused feedbacks must be set to
Source , par.20-03
setpoint 1 will be used. The sum of Setpoint 1 and any other references that are
enabled (see par. group 3-1*) will be used as the PID Controller's setpoint ref-
erence.
Maximum
[4] sets up the PID Controller to compare Feedback 1, Feedback 2 and Feedback 3 and
use the highest value as the feedback.
NB!
Any unused feedbacks must be set to
Source , par.20-03
Only Setpoint 1 will be used. The sum of Setpoint 1 and any other references that are enabled (see
par. group 3-1*) will be used as the PID Controller's setpoint reference.
Multi-setpoint minimum
[5] sets up the PID Controller to calculate the difference between Feedback
1 and Setpoint 1, Feedback 2 and Setpoint 2, and Feedback 3 and Setpoint 3. It will use the feed-
back/setpoint pair in which the feedback is the farthest below its corresponding setpoint reference.
If all feedback signals are above their corresponding setpoints, the PID Controller will use the feed-
back/setpoint pair in which the difference between the feedback and setpoint is the least.
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
No Function
in par.20-00
Feedback 2 Source , or par.20-06 Feedback 3 Source
No Function
in par.20-00
Feedback 2 Source , or par.20-06 Feedback 3 Source
No Function in par.20-00
Feedback 2 Source , or par.20-06 Feedback 3 Source
No Function in par.20-00
Feedback 2 Source , or par.20-06 Feedback 3 Source
3
Feedback 1
.
Feedback 1
. The sum
Feedback 1
. Only
Feedback 1
.
149
