3 Parameter Description
15-21 Historic Log: Value
Array [50]
Range:
0 N/A* [0 - 2147483647 N/A]
3
15-22 Historic Log: Time
Array [50]
Range:
0 ms* [0 - 2147483647 ms]
3.12.5 15-3* Alarm Log
Parameters in this group are array parameters, where up to 10 fault logs can be viewed. [0] is the most recent logged data, and [9] the oldest. Error
codes, values, and time stamp can be viewed for all logged data.
15-30 Alarm Log: Error Code
Array [10]
Range:
0 N/A* [0 - 255 N/A]
15-31 Alarm Log: Value
Array [10]
Range:
0 N/A* [-32767 - 32767 N/A]
15-32 Alarm Log: Time
Array [10]
Range:
0 s* [0 - 2147483647 s]
15-33 Alarm Log: Date and Time
Range:
0 N/A* [0 - 0 N/A]
15-34 Alarm Log: Status
Range:
0 N/A* [0 - 1 N/A]
130
Function:
View the value of the logged event. Interpret the event values according to this table:
Digtal input
Digital output (not monitored in
this SW release)
Warning word
Alarm word
Status word
Control word
Extended status word
Function:
View the time at which the logged event occurred. Time is measured in ms since frequency converter
start. The max. value corresponds to approx. 24 days which means that the count will restart at
zero after this time period.
Function:
View the error code and look up its meaning in the
Function:
View an extra description of the error. This parameter is mostly used in combination with alarm 38
'internal fault'.
Function:
View the time when the logged event occurred. Time is measured in seconds from frequency con-
verter start-up.
Function:
Array parameter; Date & Time 0 - 9: This parameter shows at which time the logged event occurred.
Function:
Array parameter, status value 0 - 9. This parameter shows the status of the alarm:
0: Alarm inactive
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
®
ADAP-KOOL Drive Programming Guide
Digital Input
Decimal value. See par.16-60
after converting to binary value.
Decimal value. See par. 16-66 Digital Output [bin]
scription after converting to binary value.
Warning Word
Decimal value. See par. 16-92
tion.
Alarm Word
Decimal value. See par. 16-90
Decimal value. See par.16-03 Status Word
after converting to binary value.
Decimal value. See par.16-00 Control Word
Ext. Status Word
Decimal value. See par. 16-94
scription.
Troubleshooting
chapter.
for description
for de-
for descrip-
for description.
for description
for description.
for de-
