ADAP-KOOL Drive Programming Guide
5-16 Terminal X30/2 Digital Input
Option:
[0] * No operation
5-17 Terminal X30/3 Digital Input
Option:
[0] * No operation
5-18 Terminal X30/4 Digital Input
Option:
[0] * No operation
3.7.4 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital outputs are common for terminals 27 and 29. Set the
I/O function for terminal 27 in par. 5-01
cannot be adjusted while the motor is running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready / remote control
[4] Stand-by / no warning
[5] Running
[6] Running / no warning
[8] Run on reference / no warning
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedback range
[19] Below feedback low
[20] Above feedback high
[21] Thermal warning
[25] Reverse
[26] Bus OK
Function:
This parameter is active when option module MCB101 is installed in the frequency converter. Func-
tions are described under 5-1*
Function:
This parameter is active when option module MCB101 is installed in the frequency converter. Func-
tions are described under 5-1*
Function:
This parameter is active when option module MCB101 is installed in the frequency converter. Func-
tions are described under 5-1*
Terminal 27 Mode
, and set the I/O function for terminal 29 in par. 5-02
The digital outputs can be programmed with these functions:
Default for all digital outputs and relay outputs
The control board receives supply voltage.
The frequency converter is ready for operation and applies a supply signal on the control board.
The frequency converter is ready for operation and is in Auto On mode.
The frequency converter is ready for operation. No start or stop command is been given (start/
disable). There are no warnings.
The motor is running.
The output speed is higher than the speed set in par. 1-81
The motor is running and there are no warnings.
The motor runs at reference speed.
An alarm activates the output. There are no warnings.
An alarm or a warning activates the output.
The torque limit set in par. 4-16 or par. 1-17 has been exceeded.
The motor current is outside the range set in par. 4-18.
The motor current is lower than set in par. 4-50.
The motor current is higher than set in par. 4-51.
The output speed is outside the range set in par. 4-52 and 4-53.
The output speed is lower than the setting in par. 4-52.
The output speed is higher than the setting in par. 4-53.
The feedback is outside the range set in par. 4-56 and 4-57.
The feedback is below the limit set in par. 4-56 Warning Feedback Low.
The feedback is above the limit set in par. 4-57
The thermal warning turns on when the temperature exceeds the limit in the motor, the frequency
converter, the brake resistor, or the thermistor.
Reversing. Logic '1' = relay activated, 24 V DC when CW rotation of the motor. Logic '0' = relay not
activated, no signal, when CCW rotation of the motor.
Active communication (no time-out) via the serial communication port.
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
Terminal 29 Mode
. These parameters
Min Speed for Function at Stop [RPM]
Warning Feedback High
.
