Danfoss ADAP-KOOL Drive Programming Manual page 58

3 Parameter Description
3-10 Preset Reference
Array [8]
Range:
0.00 %* [-100.00 - 100.00 %]
3
3-11 Jog Speed [Hz]
Range:
10.0 Hz* [0.0 - par. 4-14 Hz]
3-13 Reference Site
Option:
[0] * Linked to Hand / Auto
[1] Remote
[2] Local
3-14 Preset Relative Reference
Range:
0.00 %* [-100.00 - 100.00 %]
58
Function:
Enter up to eight different preset references (0-7) in this parameter, using array programming. The
preset reference is stated as a percentage of the value Ref
Maximum Reference/Feedb.
closed loop see par. CL-14
set ref. bit 0 / 1 / 2 [16], [17] or [18] for the corresponding digital inputs in parameter group 5-1*
Digital Inputs.
Function:
The jog speed is a fixed output speed at which the frequency converter is running when the jog
function is activated.
Jog Ramp Time
See also par.3-80 .
Function:
Select which reference site to activate.
Use local reference when in Hand mode; or remote reference when in Auto mode.
Use remote reference in both Hand mode and Auto mode.
Use local reference in both Hand mode and Auto mode.
NB!
When set to Local [2], the frequency converter will start with this setting again
following a 'power down'.
Function:
The actual reference, X, is increased or decreased with the percentage Y, set in par.3-14
Relative Reference
. This results in the actual reference Z. Actual reference (X) is the sum of the
Reference 1 Source
inputs selected in par.3-15
3 Source Control Source
and par.8-02
MG.11.N1.02 - VLT ® is a registered Danfoss trademark
®
ADAP-KOOL Drive Programming Guide
(par.3-03 Maximum Reference
MAX
). When using preset references, select Pre-
Reference 2 Source
, par.3-16
.
, for
Preset
Reference
, par.3-17
