Ath Disconnect Existing Connection; Ati Display Product Identification Information - SimCom SIM7000 Series At Command Manual

<value>
Parameter Saving
Mode
Max Response -
Time
Reference Note
V.25ter
2.2.4

ATH Disconnect Existing Connection

ATH Disconnect Existing Connection
Execution Response
Command Disconnect existing call by local TE from Command line and terminate call
ATH OK
Note: OK is issued after circuit 109(DCD) is turned off, if it was previously
on.
Parameter Saving NO_SAVE
Mode
Max Response 20s
Time
Reference Note
V.25ter
2.2.5

ATI Display Product Identification Information

ATI Display Product Identification Information
Execution Response
Command TA issues product information text
ATI
Example:
SIM7000 R1351
OK
Parameter Saving NO_SAVE
Mode
Max Response -
Time
Reference Note
V.25ter
SIM7000 Series_AT Command Manual_V1.03
0 Echo mode off
1 Echo mode on
20
Smart Machine Smart Decision
2018-05-08
