- Page 1 Application Simplify Communication SIM7060 Series_GNSS_Application Note Version: 1.03 Release Date: May.23, 2019 Simplify Communication www.simcom.com...
-
Page 2: About Document
Band 1/2/3/4/5/8/12/13/17/18/19/20/25/26/28/66/70/71 Copyrights This document contains proprietary technical information which is the property of SIMCom Wireless Solutions Co.,Ltd. Copying of this document and giving it to others and the using or communication of the contents thereof, are forbidden without express authority. -
Page 3: Table Of Contents
GNSS Example ........................ 8 Appendix ..........................10 A Terms and Abbreviations ....................10 Contact ..........................11 Figure and Table Figure 1 SIM7060 series system connection ................4 Table 1 AT+CGNSINF return parameters ................6 SIM7060 Series_GNSS_Application Note Page 3 / 11... -
Page 4: Purpose Of This Document
Developers could understand and develop application quickly and efficiently based on this document. 2 Introduction SIM7060 series module combines GNSS technology for satellite navigation. Featuring an industry-standard interface and GNSS function, it allows variable assets to be tracked seamlessly at any location and anytime with signal coverage. -
Page 5: At+Cgnspwr Gnss Power Control
Simplify Communication AT+CGNSRST GNSS Reset Mode AT+CGNSTST Send data received from GNSS to AT UART 3.1 AT+CGNSPWR GNSS Power Control AT+CGNSPWR GNSS Power Control Test Command Response AT+CGNSPWR=? +CGNSPWR: (list of supported <mode>s) Parameters See Write Command Read Command Response AT+CGNSPWR? TA returns the current status of GNSS Power supply +CGNSPWR: <mode>... - Page 6 Simplify Communication Satellites in View>,<GPS Satellites Used>,<GLONASS Satellites Used>,<Reserved3>,<C/N0 max>,<HPA>,<VPA> Parameters <GNSS run status> 0 GNSS off 1 GNSS on <Fix status> 0 Not fixed position 1 Fixed position See below table 1. Reference Table 1 AT+CGNSINF return parameters Index Parameter Unit Range...
-
Page 7: At+Cgnsrst Gnss Reset Mode
Simplify Communication Used Reserved3 [0,55] C/N0 max dBHz meters [0,9999.9] meters [0,9999.9] Total：(94) chars Note: 1. The range of <Fix Mode> depends on the GNSS chip used. 2. Reserved. 3.3 AT+CGNSRST GNSS Reset Mode AT+CGNSRST GNSS Reset Mode Test Command Response AT+CGNSRST=? +CGNSRST: (0-2) -
Page 8: Cme Error Code
Simplify Communication Test Command Response AT+CGNSTST=? +CGNSTST: (0-1),(1-255) Parameters See Write Command Read Command Response AT+CGNSTST? +CGNSTST: <mode> Parameters See Write Command Write Command Response AT+CGNSTST=<mod e>[,<cont>] ERROR Parameters <mode> 0 Turn off GNSS test mode 1 Turn on GNSS test mode <cont>... - Page 9 Simplify Communication 528,114.600,0.28,0.0,1,,1.9,2.2,1.0,,8,4,,,42,, AT+CGNSRST=0 Restart GNSS in cold start mode AT+CGNSTST=1 Send NMEA data to AT UART SIM7060 Series_GNSS_Application Note Page 9 / 11...
-
Page 10: Appendix
Simplify Communication Appendix A Terms and Abbreviations Abbreviation Definition Access Point Name Unsolicited Result Code File Transfer Protocol Global Positioning System Fixed Data Geographic Position - Latitude/Longitude GNSS Global Navigation Satellite System Global Positioning System AGPS Assisted GPS DGPS Differential Global Positioning System GPRS General Packet Radio Service GNSS DOP and Active Satellites... -
Page 11: Contact
Simplify Communication Contact SIMCom Wireless Solutions Co.,Ltd Address: Building B, 6F, No.633 Jinzhong Road, Changning District, Shanghai P.R.China 200335 Tel: +86 21 3157 5126 Email: support@simcom.com Website: www.simcom.com SIM7060 Series_GNSS_Application Note Page 11 / 11...
