15.2.9 AT+CGNSCFG GNSS NMEA Out Configure

AT+CGNSCFG GNSS NMEA Out Configure
Test Command Response
AT+CGNSCFG= +CGNSCFG: (list of supported <mode>s )
?
OK
Parameters
See Write Command
Read Command Response
AT+CGNSCFG? TA returns the current status of configure
+CGNSCFG: <mode>
OK
Parameters
See Write Command
Write Command Response
AT+CGNSCFG= OK
<mode> or
ERROR
Parameters
<mode>
when set AT+CGNSPWR=1/0
when set AT+CGNSPWR=1/0
set AT+CGNSPWR=1/0
Parameter Saving NO_SAVE
Mode
Max Response -
Time
Reference Note
This command only supported in UART port.
SIM7000 Series_AT Command Manual_V1.03
0 Turn off GNSS NMEA data out put to USB's NMEA port
through UART
1 Turn on GNSS NMEA data out put to USB's NMEA port
through UART
2 Turn on GNSS NMEA data out put to UART3 port when
