6 APPENDIX

6.1 How to update a new firmware into the MAMBOII

Please, refer to the separate manual "MAMBOII_hardware_guide.pdf", chapter
Appendix, section 6.2.

6.2 Supported dynamic entries

The following table shows the dynamic entries that can be attached to the user
specified text when they are requested.
Entry
SYS
SecurityLock
DeviceName
VAccu
Timer<index>
Trigger<index>
Counter<index>
SerialData
StartupReason
IO
IN<>
Out<>
ANA<>
GPS
Time
Date
SysTime
SysDate
Lat.n
Lon.n
Lat
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
Meaning (for more details, refer also to the corresponding PFAL command respectively)
Used to report whether or not the MAMBOII device has already been locked. If system
MAMBOII has already been locked, the return value is 1, otherwise it returns 0
Used to report the device name.
Used to report the internal battery voltage. Battery voltage will be available approx. 6-10
seconds after the system start-up. The unit of the retrieved value is Volt.
Used to request the state of the selected Timer. The <index> Determines the index of
the timer to be requested. Up to 20 Timers are available. It can be set to a value from 0
to 19.
Used to request the state of the selected Trigger. The <index> Determines the index of
the trigger to be requested. Up to 20 Timers are available It can be set to a value from 0
to 19
Used to request the state of the selected Counter. The <index> Determines the index of
the counter to be requested. Up to 20 Timers are available. It can be set to a value from
0 to 19
Used to report the last string received from the serial interface, which is terminated by a
Carriage Return and Line Feed.
Used to report in which way system is last started. Following strings can be reported:
Start Normal boot
Reset When it reboots
Motion When it wakes up from the MOTION-Sleep
Ign When it wakes up from the IGN-sleep
Ring When it wakes up from the Ring-sleep
Time When it wakes up from the Timer-sleep
Used to report the state of the digital inputs. The <> determines the index of the input to
be requested. It can be set to a value from 0 to 3.
Used to report the state of the digital outputs. The <> determines the index of the output
to be requested. It can be set to a value from 0 to 1.
Used to report the state of the analogue inputs. The <> determines the index of the
analogue inputs to be requested. It can be set to a value from 0 to 3.
Used to report the current system time (e.g. the time when a specific event occurred).
The system time is expressed in Coordinated Universal Time (UTC).
Used to report the current system date (e.g. the date when a specific event occurred).
Used to request the current internal time of the device. The time in the time format
"hh:mm:ss". It is the time since the device has been running. The time value will be set
to 0 each approx. 50 days.
Used to request the current internal date of the device. The date in the date format
"dd:mm:yy". It is the date since the device has been running. The time value will be set
to 0 each approx. 50 days.
Used to report the current GPS latitude value in nautical coordinates. Format: is e.g.
50N40'23" for north, 50°40'23".
Used to report the current GPS longitude value in nautical coordinates. Format: is e.g.
010E58'50 for east, 10°58'50".
Used to report the current GPS latitude value in decimal degrees.
