FALCOM MAMBOII User Manual page 26

C C
ONFIGURATION OMMAND
PFAL COMMAND SET
$PFAL,Sys.Timer<index>.Arm
$PFAL,Sys.Timer<index>.Disarm
$PFAL,Sys.Timer<index>.Erase
$PFAL,Sys.Timer<index>.Save<storage_index>
$PFAL,Sys.Timer<index>.Load<storage_index>
$PFAL,Sys.Timer<index>.State
$PFAL,Sys.Trigger<index>=<state_type>
$PFAL,Sys.Trigger<index>
$PFAL,Sys.Trigger<index>.Save<storage_index>
$PFAL,Sys.Trigger<index>.Load<storage_index>
$PFAL,Sys.Counter<index>.Set=<value>
$PFAL,Sys.Counter<index>.Increment=<inc_value>
$PFAL,Sys.Counter<index>.Decrement=<dec_value>
$PFAL,Sys. Counter<index>.State
$PFAL,Sys.Counter<index>.Save<storage_index>
$PFAL,Sys.Counter<index>.Load<storage_index>
$PFAL,Sys. Counter<index>.Clear
$PFAL,Sys.Macro<index>
$PFAL,Sys.GSM.Enable
$PFAL,Sys.GSM.Disable
$PFAL,Sys.GSM.Reset
$PFAL,Sys.GPS.Enable
$PFAL,Sys.GPS.Disable
$PFAL,Sys.GPS.Reset
$PFAL,Sys.UserEvent<index>
$PFAL,Sys.Bat.Voltage
$PFAL,Sys.Bat.ChargeState
$PFAL,Sys.BT.Enable
$PFAL,Sys.BT.Disable
$PFAL,Sys.BT.Reset
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
S - F R
ET IRMWARE
2.4.0_ -
EVISION BETA
MEANING
Arms an initialized and disarmed timer
Disarms an initialized and armed timer
Erases the configuration of a timer
Saves a timer state to a storage index
Loads the saved timer state from a storage index
Reads the state of a used timer
Activates/deactivates a system trigger
Retrieves the current trigger state
Saves the state of trigger to a storage index
Loads a saved trigger from a storage index
Sets the value of a counter
Increments the value of a counter
Decrements the value of a counter
Retrieves the state of a used counter
Saves the state of the counter to a storage index
Loads a saved counter from a storage index
Sets a specified counter to 0
Activates a configured macro
Powers on the GSM engine
Powers off the GSM engine
Resets the GSM engine
Powers on the GPS engine
Powers off the GPS engine
Resets the GPS engine
Creates a user-event for specific application
requirements
Queries the battery voltage.
Query whether the internal battery is currently
charging.
Powers on Bluetooth module
Powers off Bluetooth module
Resets Bluetooth module
V 1.0.0
ERSION
Chapter
3.2.1.4.6
3.2.1.4.7
3.2.1.4.8
3.2.1.4.9
3.2.1.4.10
3.2.1.4.11
3.2.1.5.1
3.2.1.5.2
3.2.1.5.3
3.2.1.5.4
3.2.1.6.1
3.2.1.6.2
3.2.1.6.3
3.2.1.6.4
3.2.1.6.5
3.2.1.6.6
3.2.1.6.7
3.2.1.7.1
3.2.1.8.1
3.2.1.8.2
3.2.1.8.3
3.2.1.9.1
3.2.1.9.2
3.2.1.9.3
3.2.1.10.1
3.2.1.11.1
3.2.1.11.2
3.2.1.12.1
3.2.1.12.2
3.2.1.12.3
Page 26 of 271
